1Hz-150 Khz Signal Generator PWM Board

Marke / Kategorie: RoboMall unter Erweiterungsmodule > Module > Strom / Spannung

1Hz-150 Khz PWMSignalgenerator mit deutlich lesbarem LCD-Display zum Anzeigen von Frequenz und Duty cycle. Der PWM-output kann einfach und seperat eingestellt werden. Das Modul unterstützt auchserielle Kommunikation Ideal zum experimentieren und entwickeln von Microcontroller und Schrittmotor-Anwendungen. Frequency is divided into four ranges, automatic switching:
1. XXX (no decimal point): the smallest unit is 1Hz, the value range of 1Hz ~ 999Hz;
2. X.XX (decimal point in the hundred) the smallest unit is 0.01Khz, the range of 1.00Khz ~ 9.99Khz;
3. XX.X (decimal point in ten): the smallest unit is 0.1Khz; value range of 10.0KHz ~ 99.9KHz
4. X.X.X (decimal point in ten and hundred): the smallest unit is 1Khz; value range 1KHz ~ 150KHz
e.g. frequency display: 100 indicates PWM output 100Hz pulse;
1.01 indicates PWM output 1.01K pulse;
54.1 indicates that the PWM output has a pulse of 54.1 kHz;
1.2.4 indicates that the PWM output is 124 kHz pulse; Details:

• Duty cycle range: 0 ~ 100%;
• All set parameters, power down save.
• Working voltage: 3.3 ~ 30V;
• Frequency range: 1Hz ~ 150KHz;
• Frequency accuracy: the accuracy in each range is about 2%;
• Signal load capacity: the output current can be about 5 ~ 30ma;
• Output amplitude: PWM amplitude equal to the supply voltage;
• Ambient temperature: -20 ~ +70 ?.

• 1x 1Hz-150 Khz Signal Generator PWM Board
